K20-Data Collection Terminals-Kilichain

Key Features

IP68 Protection Level

A more stringent protection level IP68 to meet the requirements of operations in complex environments. No fear of outdoor damp and dusty environments.

Large Capacity Removable Battery

The 5000 mAh lithium polymer removable battery ensures long battery life. The removable feature supports quick replacement of backup batteries without worrying about the complicated maintenance process caused by battery failure.

Big Speaker and Big Screen

The 6.3-inch high-definition display screen (1520*720) makes touch-screen operation accurate and easy. Large speakers enable portable teams to communicate without obstacles even in noisy environments.

8-Core Processor

The 8-core processor makes data collection faster and smoother, and software APP runs more smoothly. It supports WiFi, Bluetooth and communication networks of various frequency bands.

Specification Excerpts

Performances

Network frequency band	2G: GSM 850/900/1800/1900MHz 3G: WCDMA B1/2/4/5/8; TD-SCDMA B34/B39 4G: FDD-LTE: B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28A/28B, TDD-LTE: B34/38/39/40/41
Operating system	Android 11
Running memory	4GB RAM
Storage memory	64GB ROM, maximum support TF card memory expansion up to 128GB
Bluetooth	5.0 version
Navigation system supports	GPS+GLONASS+Beidou
Camera	Triple camera: 24 million pixel main camera + 2 million pixel macro, with flash; front 5 million pixel camera
Sensor	Accelerometer, light sensor, distance sensor, gyroscope sensor, geomagnetic sensor, pedometer

Physicals

Size	1758216 mm
Net weight	326g
Color	Black, Orange
Waterproof grade	IP68
Working temperature	-10 °C to +50 °C (14 ℉ to +122 ℉)
Storage temperature	-40 °C to +70 °C (-40 ℉ to +158 ℉)

Electricals

Battery

Removable 3.8V/5000mAh battery
