AUP305-Unmanned & Automated Systems-Kilichain

Overview

The AUP305 Auto Steering system is our automated steering solution for the precision agriculture industry. The integrated motor-driven steering wheel design ensures quick and easy installation and removal. The user-friendly interface gets you up and running within 20 minutes. Its app allows real-time path planning, including turns, straight lines, and curves. It enables quick farming tool alignment and real-time remote monitoring for precise autosteering that saves time and increases efficiency. You can operate confidently and efficiently by relying on our market-proven technology backed by 24/7 remote support from a globally deployed service network.

Key Features

ISOBUS Support

The support of ISOBUS allows other devices to be compatible with our equipment, and at the same time enables the expansion of more functions and the diversification of solutions.

High RTK Accuracy Available

AUP305 Auto Steering system receiver supports RTK, and stably achieves centimeter-level positioning and navigation, realizing high-precision automatic navigation and steering of tractors, bringing more production benefits to cultivated operations.

Mini Speed 0.1KM/H

The system data is updated steadily and quickly, which supports our system to support the tractor to complete the operation at a flexible pace, and set the appropriate driving state according to different farmland operating environments.

Path Planning

The path planning function enables the tractor operation to plan the most suitable tractor running route according to different farmlands, and improves land utilization rate and operation efficiency.

Specification Excerpts

Performances

GNSS Receiver
RTK Positioning Accuracy (RMS)	Horizontal: 8 mm + 1 ppm Vertical: 15 mm + 1 ppm Initialization Time: <5 s (typical) Initialization Reliability: >99.9% First Fix Time: <30 s
Constellation	BDS, GPS, GLONASS, Galileo, QZSS, SBAS, L-band
Frequency Bands	BDS: B1I/B2I/B3I/B1C/B2b GPS: L1C/A/L2P(Y)/L2C/L5 Galileo: E1/E5a/E5b/E6* GLONASS: G1/G2 QZSS: L1C/A/L2C/L5 SBAS: L1C/A
Steering and Control Section
Data Interface	CANBUS RS232 AD conversion
Tablet Display
LED Display	10.1 inches, 1280 x 800 p, 750 nits
I/O Interface	DI * 2, DO * 2 USB 2.0 * 1 12 V DC output * 2
Operation system	Android 12.0

Physicals

Steer Part
Peak torque	9 N•m
Dimensions (diameter)	181.5 mm
Height	60.4 mm
Weight	2.8 kg
Working temperature	-20 to +70 °C
Storage temperature	-40 to +85 °C
Exterior material	Aluminum alloy
Rated speed	100 rpm

Electricals

Steer Motor
Motor voltage supply range	9–36 V DC

*All specifications are subject to change without notice.

(1) Accuracy depends on the open sky, free of multipaths, optimal GNSS geometry and atmospheric condition. (2) Battery life is subject to the particular operating temperature.
