KV8-Satellite Communications-Kilichain

Overview

KV8 maritime VSAT satellite communication antennasystem offers exceptional value and superior RF performance makes it suitable for bigger vessels, ensuringeasy operation on board as well as access to remote supportwhenever needed. It delivers superior tracking performance, enabling users to enjoy remote control via PC &mobiledevices, web surfing, broadb and connectivity, videomonitoring, video conferencing, VolP&other networkapplications during dynamic sea conditions.

Key Features

High Tracking Accuracy

Adopting an upper inertial navigation scheme, an accurate error model, and efficient compensation and correction of errors, resulting in high tracking accuracy.

Stable and Reliable Tracking

Adoption of reflector surface tracking algorithm, based on three-dimensional relationships of signal level, azimuth angle, and elevation angle, ensuring stable and reliable tracking.

Modem Compatability

Compatible with a variety of modems, iDirect, UHP, Newtec, Gilat, Comtech, Hughes, Anovo, Spacebridge and many more.

Advanced System Control

The ACU has built-in Wi Fi, allowing wireless device users to directly connect. Advanced system control and antenna status monitoring can be achieved using an ACU web interface.

Specification Excerpts

Performances

Stabilization forms	3-axis stabilized: Azimuth, Elevation, Roll
Tracking forms	4-axis stabilized: Azimuth, Elevation, Roll, Skew
Tracking &location mode	Built-in inertial guidance & BDS/GPS
Azimuth range/tracking rate	Unlimited/±90°@36S
Elevation range/tracking rate	-10°~105/±20°@5S
Roll range/tracking rate	±35°%±20°@5S
Skew range	±167.5°
Initial lock	≤60S
Re-lock after break lock time	Break lock<30S; Re-lock<3S
Tracking braking system	Azimuth, Elevation, Roll, Skew

Physicals

Radome height	102cm (40.16 inch)
Radome diameter	104.6 cm (41.18inch)
Reflector diameter	83 cm (32.7 inch)
Antenna weight	58kg/128Ibs
Working temperature	-20℃ to +60℃ (-4℉ to +140℉)
Waterproofing grade	IP56
Satellite band	KU-Band
ACU size	35023050.98mm (Without bracket)
ACU weight	2.9kg

Electricals

Power input	AC: 100V~240V/50Hz DC: 15-36V
Power output	DC: 24V
Static power	37W (Without BUC power)
Dynamic power	57W (Without BUC power
BUC power	4W / 6W / 8W / 16W (Optional)
