Satellite CommunicationsKV10
Ideal for Deep-Ocean Vessels With High Demands for Onboard Broadband Services
Inquiry
Overview
Key Features
Parameters
Applications
Download
Related Products
Overview
KV10 is a 105cm Ku-Band maritime VSAT antenna system ideal for global commercial vessels, offshore vessels, oil and gas platform etc. With its 3-axis stabilized platformand 5 patent technologies, KV10 offers superior high tracking performance, supporting remote control by PC and mobile, video monitoring, broadband, video conference, VolPand other network applications. With the ability to select from a range of satellites, the KV10 is ideal for deep-ocean vessels with high demands for onboard broadband services.
Key Features
High Tracking Accuracy
Adopting an upper inertial navigation scheme, an accurate error model, and efficient compensation and correction of errors, resulting in high tracking accuracy.
Stable and Reliable Tracking
Adoption of reflector surface tracking algorithm, based on three-dimensional relationships of signal level, azimuth angle, and elevation angle, ensuring stable and reliable tracking.
Modem Compatability
Compatible with a variety of modems, iDirect, UHP, Newtec, Gilat, Comtech, Hughes, Anovo, Spacebridge and many more.
Advanced System Control
The ACU has built-in Wi Fi, allowing wireless device users to directly connect. Advanced system control and antenna status monitoring can be achieved using an ACU web interface.
Specification Excerpts
Performances
Stabilization forms3-axis stabilized:  Azimuth, Elevation, Roll
Tracking forms

4-axis stabilized: Azimuth, Elevation, Roll, Skew

Tracking &locationmodeBuilt-in inertial guidance &BDS/GPS
Azimuth range/tracking rateUnlimited/±90°@36S
Elevation range/tracking rate-5°~112/±20°@5S
Roll range/tracking rate±38%±20°@6S
Skew range/trackingrate±90°
Initial lock≤118S
Re-lock after break locktimeBreak lock<60S; Re-lock<60S
Tracking braking systemAzimuth, Elevation, Roll, Skew


Physicals
Radome height140.0 cm (55.1 inch)
Radome diameter134 cm (52.8 inch)
Reflector diameter105cm (41.3 inch)
Weight115kg (253lbs)
Working temperature-20 ℃ to +60 ℃ ( -4 ℉ to + 140 ℉)
Waterproofing gradeIP56
Satellite bandKU-Band
ACU size350*230*50.98mm (Without bracket)
ACU weight2.9 kg


Electricals


Power inputAC: 100V-240V/50Hz DC: 15-36V
Power outputDC: 24V
Static power33W (Without BUC power)
Dynamic power44W (Without BUC power)
BUC power4W / 6W / 8W / 16W (Optional)


Applications
Merchant Marine Communications Freighter Communications Fishing Vessel Communications Official Ship Cmmunications Emergency Communications
