GNSS ModulesRTK1000
High Precision Differential Positioning GNSS Module
Inquiry
Overview
Key Features
Parameters
Applications
Download
Related Products
Overview
Multi-band module provides centimeter-level positioning accuracy in seconds, and supports simultaneous reception of GPS, GLONAsS, Galileo and BDS. 5Hz real-time data output for autonomous driving High-precision mapping.
Key Features
Full Constellation Multi-Band
The module supports GPS LIC/A L2C,GLONASS LIOF L2OF,GALILEO EIB/C ESb,BDS BII/B21.
Data Security and Stability
Advanced anti-interference technology and calibration technology ensure security of location and navigation information.
PC Software to Support
Easy to view data and mapping track,One-key configuration of mobile station and base station.
Real Time Data Output
5Hz real-time data output for autonomous driving and high-precision mapping.
Specification Excerpts
Performances
GPS
L1, L2
GLONASSG1, G2
GalileoE1, E5b
BDSB1, B2
QZSL1, L2
Real time kinematics (RTK)

Horizontal: 1cm+1ppm CEP

Vertical: 1cm+1ppm CEP

Single point

Horizontal: 1.5 CEP

Vertical: 1.5 CEP

Speed accuracy 0.05m/s
Heading angle accuracy
0.4 deg
Dynamic heading angle accuracy
0.3 deg
1pps time accuracyRMS 30 ns

99% 60 ns


Physicals
Size56mm x 45mm x 10mm
Working temperature-40  ℃ to +80 ℃ (-40 ℉ to +176 ℉)
Storage temperature-40  ℃ to +105 ℃ (-40 ℉ to +221 ℉)




Electricals
VoltageDC: 3.6V-6.0V, typical: 5.0V
Current 80mA/5.0V

*All specifications are subject to change without notice.

(1)Accuracy depends on the open sky,freeof multipaths,optimalGNSS geometry and atmospheric condition.


Applications
High Precision Auto Driving
