Overview

DT50 is an external high-power transceiver data radio, specially developed for the surveying and mapping market, with the characteristics of long communication distance, low power consumption, intelligent and user-friendly design. It mainly has high-definition OLED display, support menu operation, intelligent recognition of serial port baud rate, intelligent identification of boot status, interference detection, remote control and other functions.

Key Features

Variety of Working Modes

It supports multiple working modes of single transmission, integrated transceiver, radio relay and network trunk.

Multi-mode Data Transmission Channels

Support RS232 serial port and Bluetooth two data transmission channels.

OLED Display Configuration Station Operation

It allows users to easily and quickly configure radio parameters and query the status of radio stations through the local display.

Advanced and Efficient Communication Protocol

Under the same communication conditions, DT50's unique communication protocol can reduce the bit error rate in the case of weak signals, and the communication distance can be increased by about 20% compared with other protocols.

Specification Excerpts

Performances

Frequency	410MHz-470MHz
Operating mode	Transmitter
Channel width	12.5KHz/25KHz
Channels	15 channels (user selectable)
Operating voltage	9-16V
Power consumption	Transmit output power H: (30W) 85W@12V DC Transmit output power M: (22W) 60W@12V DC Transmit output power L: (5W) 35W@12V DC Sleep state 2W@12V DC
Frequency stability	≤±1ppm
Ingress protection rating	IP67

Physicals

Size	175 mm x 130 mm x 86.5 mm (HWD)
Weight	2 kg
Working temperature	-40℃ to +65℃ (-40℉ to +149℉)
Storage temperature	-50℃ to +85℃ (-58℉ to +185℉)

Electricals

RF output power

H: 30W 45.4±0.5dBm @12V DC

M: 22W 43.4±0.5dBm@12V DC

L: 5W 37±1dBm@12V DC

RF output stability

±1dB
